Pulsafeeder DM3C1FG Mechanically Actuated Diaphragm Metering Pump – Green Line Series, 33 GPH – 102 PSI
Original price was: $4,037.00.$3,391.10Current price is: $3,391.10.
Pulsafeeder DM3C1FG Mechanically Actuated Diaphragm Metering Pump – 33 GPH, 102 PSI
The Pulsafeeder DM3C1FG delivers accurate chemical dosing up to 33 GPH at 102 PSI for industrial water treatment systems.
This mechanically actuated diaphragm metering pump features a PTFE-faced diaphragm for chemical resistance and long life. The double-seal design improves leak protection. Balanced check valves maintain smooth, consistent flow.
A sealed gearbox and auto-locking stroke adjustment ensure reliable, low-maintenance operation.
Ideal for cooling towers, boilers, and industrial chemical dosing applications.
Technical Specifications
| Specification | Details |
|---|---|
| Model | DM3C1FG (Green Line Series) |
| Pump Type | Mechanically Actuated Diaphragm Metering Pump |
| Flow Capacity | Up to 33 GPH |
| Maximum Pressure | 102 PSI |
| Diaphragm Material | Multi-layer PTFE-faced diaphragm |
| Valve Design | Spherically balanced check valves |
| Sealing System | Double-seal diaphragm with secondary O-ring |
| Stroke Adjustment | Auto-locking manual adjustment |
| Gearbox | Fully enclosed, sealed gearbox |
| Motor Coupling | Non-metallic |
| Mounting | Flat, stable mounting feet |
| Optional Features | Leak detection system, VFD compatible motor |
| Applications | Industrial water treatment, cooling towers, boiler systems, chemical process dosing |
Precision Dosing with the Pulsafeeder DM3C1FG Green Line Metering Pump
The Pulsafeeder DM3C1FG mechanically actuated diaphragm metering pump delivers accurate and consistent chemical dosing for industrial water treatment systems. It provides up to 33 GPH at 102 PSI, making it ideal for higher-capacity applications.
In addition, the multi-layer PTFE-faced diaphragm resists aggressive chemicals and extends service life. The double-seal diaphragm system improves leak protection and prevents chemical spray. As a result, operators gain safer and more reliable performance.
Moreover, spherically balanced check valves maintain smooth flow and improve solids handling. The sealed gearbox protects internal components from contamination and reduces maintenance. The auto-locking stroke adjustment keeps settings secure during operation.
Because of its rugged construction and steady output, this Green Line metering pump performs well in cooling towers, boiler systems, and industrial process dosing applications.
Finally, available from Water Treatment Supply, the Pulsafeeder DM3C1FG offers strength, durability, and dependable chemical feed control for demanding environments.
Specifications and Use Cases of Pulsafeeder DM3C1FG Green Line Metering Pump
The Pulsafeeder DM3C1FG Green Line metering pump features a mechanically actuated PTFE-faced diaphragm with manual stroke adjustment for accurate flow control. Rated up to 33 GPH at 102 PSI, it supports demanding industrial applications that require consistent, high-capacity chemical dosing.
Its double-seal diaphragm system enhances leak protection, while balanced check valves maintain smooth and stable flow. The sealed gearbox and auto-locking stroke mechanism ensure durable, low-maintenance operation in continuous-duty environments.
Use Cases & Industry Applications:
● Water Treatment Systems: Provides reliable dosing of corrosion inhibitors, biocides, and treatment chemicals.
● Boiler Feed Systems: Maintains water chemistry and protects equipment from scale and corrosion.
● Cooling Towers: Delivers precise chemical feed to improve efficiency and system cleanliness.
● Industrial Process Systems: Supports consistent chemical injection in manufacturing and processing plants.
● Power Plants & Utilities: Handles higher-capacity dosing requirements with stable pressure control.
● Chemical Injection Skids: Integrates easily into packaged systems for automated process control.
No replacement parts listed for this item yet.
FAQs
1. What is the flow capacity of the Pulsafeeder DM3C1FG?
It delivers up to 33 gallons per hour (GPH) with adjustable manual stroke control for accurate dosing.
2. What is the maximum operating pressure?
The pump operates at pressures up to 102 PSI, making it suitable for industrial chemical feed systems.
3. Does this pump offer leak protection?
Yes, it features a double-seal diaphragm system with a secondary O-ring to improve leak resistance and safety.
4. Can it handle aggressive chemicals?
Yes, the multi-layer PTFE-faced diaphragm provides strong chemical resistance and long service life.
5. Is the DM3C1FG easy to maintain?
Yes, the sealed gearbox, non-metallic motor coupling, and auto-locking stroke adjustment reduce maintenance and simplify service.
