Harmsco HC/40-20 | 20 Micron Pleated Polyester Filter Cartridge for HUR-40HP Housing
$125.41
- Model: HC/40-20
- Type: Premium Hurricane® Pleated Polyester Filter Cartridge
- Micron Rating: 20 Micron (Nominal)
- Dimensions:
- Length: 9-5/8 inches
- Outer Diameter: 7-3/4 inches
- Inner Diameter: 2-1/8 inches (Double Open End, DOE)
- Filter Media: Pleated Polyester-Plus™
- End Caps: Pliable PVC with built-in sealing surface
- Center Tube: ABS or PVC
- Temperature Rating: Up to 140°F (60°C)
- Pressure Rating: 150 psi
- Recommended Flow Rate: 35 GPM
- Maximum Flow Rate: 50 GPM
- Surface Area: Approximately 40 ft²
- Compatibility: Designed for use with Harmsco HUR-40HP filter housing
Description
Harmsco HC/40-20, 20 Micron Premium Hurricane Polyester Cartridge
– Fewer cartridges mean fewer replacements and cheaper maintenance costs.
– Pleated Polyester-Plus™ filter media improves flow rates and reduces initial pressure drop. – Pleated surface area increases loading capacity, resulting in extended filter life and enhanced particle removal.
– The end cap, center tube, and media are thermally fused as a single integral component for increased strength.
– Pleated Polyester-Plus™ filter media improves flow rates and reduces initial pressure drop. – Pleated surface area increases loading capacity, resulting in extended filter life and enhanced particle removal.
– The end cap, center tube, and media are thermally fused as a single integral component for increased strength.
– High Flow capability
– Lower overall operating cost
– Reduced waste disposal
– Longer filter runs for fewer change-outs
– Increased contaminant removal
– Operator friendly
– NSF Certified to ANSI-NSF 61
Applications
– Reverse Osmosis Pre-Filtration – Cooling Tower Filtration
– Municipal Drinking Water Filtration – Chill Water Loop Filtration
– Commercial/Residential Drinking Water Filtration – Food & Beverage Filtration
– Desalination Pre-Filtration – Marine/Aquatic Filtration
– Industrial Water Filtration – Industrial Coolant Filtration
– Reverse Osmosis Pre-Filtration – Cooling Tower Filtration
– Municipal Drinking Water Filtration – Chill Water Loop Filtration
– Commercial/Residential Drinking Water Filtration – Food & Beverage Filtration
– Desalination Pre-Filtration – Marine/Aquatic Filtration
– Industrial Water Filtration – Industrial Coolant Filtration
Specifications
Cleanable/Reusable in most filtration applications and micron ratings
| Micron Rating | 20 Microns |
| Media (sq ft) | 40 |
| Rec. Flow Rate (GPM) | 35 |
| Max Flow Rate (GPM)* | 50 |
| Max Flow Rate (LPM)* | 189 |
| Max Flow Rate (M3/Hr)* | 12 |
| Filter Dimension | 7-3/4″ OD x 9-5/8″ H |
| Filter Media | Nominal pleated Polyester-Plus™ |
| End Caps | Pliable PVC w/ sealing surface built in |
| Center Tubes | ABS or PVC |
| Temperature | 140°F (60°C)** |
* Harmsco Recommends operation at 70% of maximum flow rate for optimum performance
** Temperature limits vary and depend on pressure and time under load
Datasheet
