Neptune VTF-10HP (10 Gallon) Flat Bottom Bypass Feeder
Original price was: $717.00.$590.00Current price is: $590.00.18% OFF
The Neptune VTF-10HP Bypass Pot Feeder is a high-capacity, flat-bottom chemical bypass feeder designed for safe and efficient chemical dosing in commercial and industrial water treatment systems. With a 10-gallon capacity, 300 PSI pressure rating, and a maximum operating temperature of 200°F (93°C), it delivers reliable performance in demanding closed-loop applications.
Constructed from durable painted steel, the VTF-10HP features a 4-inch wide-mouth cap with a secure O-ring seal for fast chemical loading and leak-free operation. Its freestanding vertical design with demountable leg extensions provides easy installation and maintenance, while the optional filter bag kit offers additional flexibility for chemical treatment processes. The Neptune VTF-10HP is ideal for boilers, cooling towers, closed-loop systems, and other commercial or industrial water treatment applications.
Technical Specifications
| Specification | Details |
|---|---|
| Model | VTF-10HP |
| Series | Neptune VTF Series |
| Type | Bypass (Pot) Feeder – Flat Bottom |
| Material | Painted Steel |
| Capacity | 10 Gallons |
| Pressure Rating | 300 PSI |
| Maximum Temperature | 200°F (93°C) |
| Inlet/Outlet Size | 3/4″ FNPT |
| Opening Size | 3-1/2″ |
| Closure | 4″ Wide-Mouth Cap with Secure O-Ring Seal |
| Bottom Type | Flat Bottom (Dish-Bottom-In Configuration) |
| Mounting Type | Freestanding with Demountable Leg Extensions |
| System Integration | Compatible with Chemical Metering Pumps and Water Treatment Dosing Systems |
| Optional Accessories | Filter Bag Kit (Approximately 30 Micron, Sold Separately) |
| Typical Applications | Boiler Systems, Cooling Towers, Closed-Loop Systems, Commercial Water Treatment, Industrial Water Treatment, and Chemical Feed Systems |
| Build Characteristics | Corrosion-Resistant, High-Pressure Design for Continuous Industrial Operation |
Reliable High-Pressure Chemical Feed with Neptune VTF-10HP
The Neptune VTF-10HP Bypass Feeder provides safe, efficient, and controlled chemical dosing in pressurized water systems. Its flat-bottom design promotes complete chemical mixing. In addition, the wide-mouth cap makes chemical loading quick and easy.
The VTF-10HP works seamlessly with industrial chemical metering pumps, solenoid-driven metering pumps, and precision chemical dosing pumps. As a result, it delivers consistent chemical treatment in boilers, cooling towers, closed-loop systems, and other water treatment applications.
Furthermore, its rugged construction supports long-term performance in demanding commercial and industrial environments. Available from Water Treatment Supply, the Neptune VTF-10HP gives water treatment professionals a reliable solution for accurate and dependable chemical feed.
Specifications and Use Cases of Neptune VTF-10HP Bypass Feeder
Engineered for durability, the Neptune VTF-10HP withstands high pressure and temperature conditions commonly found in boiler systems, cooling towers, and closed-loop water treatment systems. Its freestanding design and optional filtration accessories make it a flexible solution for industrial installations.
Use Cases & Industry Applications:
- Boiler Water Treatment
Supports controlled chemical feed of corrosion inhibitors and conditioning chemicals. - Cooling Towers & HVAC Systems
Ensures reliable delivery of biocides, scale inhibitors, and treatment compounds. - Closed-Loop Water Systems
Ideal for maintaining water quality in pressurized recirculating systems. - Industrial Process Water Treatment
Used in manufacturing plants and processing facilities requiring stable chemical feed.
No replacement parts listed for this item yet.
FAQs
- What is the capacity of the Neptune VTF-10HP bypass feeder?
It has a total capacity of 10 gallons. - What is the maximum pressure rating?
The feeder is rated for 300 PSI at 200°F. - Is this a chemical dosing pump?
No. The VTF-10HP is a bypass feeder vessel used alongside chemical metering pumps and dosing systems. - Can it be used with high-pressure chemical dosing pumps?
Yes. It is commonly integrated with industrial and high-pressure chemical dosing pumps. - What applications is it best suited for?
Boilers, cooling towers, closed-loop systems, and industrial water treatment applications.
