Neptune VTF-5HP (5 Gallon) Flat Bottom Bypass Feeder
Original price was: $506.00.$410.00Current price is: $410.00.
The Neptune VTF-5HP bypass pot feeder provides reliable and efficient chemical dosing for closed-loop systems, boilers, and cooling towers. It features a 5-gallon flat-bottom, vertical design that supports stable installation and easy maintenance. Rated for 300 PSI at 200°F, this feeder delivers precise chemical injection for industrial and HVAC applications.
Built from painted steel for durability and corrosion resistance, the VTF-5HP includes a 4-inch wide-mouth cast iron cap with a Buna-N O-ring for secure sealing and simple refilling. Compact and dependable, it ensures consistent chemical feed and long service life in demanding environments.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Neptune VTF-5HP |
| Series | Neptune VTF Series |
| Type | Flat-bottom bypass pot feeder |
| Capacity | 5 gallons |
| Design | Vertical style, dish-bottom-in |
| Material | Painted steel construction |
| Max Pressure | 300 PSI at 200°F |
| Max Temperature | 200°F |
| Opening Size | 3-1/2 inches |
| Connection Size | 3/4″ NPT (female) |
| Lid Type | 4″ wide-mouth cast iron cap with Buna-N O-ring |
| Includes | Optional 30-micron filter bag kit (sold separately) |
| Mounting | Freestanding with demountable leg extensions |
| Weight | Approx. 37 lbs |
| Applications | Closed-loop systems, boilers, cooling towers, chemical dosing |
Smart and Reliable Chemical Dosing with the Neptune VTF-5HP
The Neptune VTF-5HP bypass pot feeder provides a smart and reliable solution for chemical dosing in closed-loop water systems. It is designed for consistent performance in demanding applications.
As part of the Neptune VTF Series, this feeder features a flat-bottom, vertical design that saves space and improves stability. Because of its heavy-duty construction, it handles pressures up to 300 PSI with confidence. As a result, it performs well in high-pressure systems.
In addition, the painted steel body resists corrosion and extends service life. The wide-mouth closure also simplifies refilling and inspection. Therefore, routine maintenance takes less time and effort.
Moreover, the Neptune VTF-5HP works well in HVAC systems, boiler water treatment, and cooling towers. Its durable design supports safe operation and consistent chemical feed in daily use.
Finally, available from Water Treatment Supply, the Neptune VTF-5HP delivers the durability, reliability, and performance professionals expect for effective water treatment and chemical dosing applications.
Specifications and Use Cases of the Neptune VTF-5HP Bypass Pot Feeder
The VTF-5HP is engineered to deliver reliable performance in both commercial and industrial environments. Its design allows for effective
chemical dosing, ensuring system efficiency and long-term protection from corrosion and scaling.
Use Cases & Industry Applications:
● Boiler Systems: Maintains water chemistry balance to prevent scale and corrosion.
● Cooling Towers: Enable accurate dosing of biocides and scale inhibitors.
● Closed-Loop HVAC Systems: Ensures corrosion control and pH stabilization.
● Industrial Water Treatment: Supports chemical addition for process efficiency.
● Commercial Facilities: Used in hospitals, hotels, and institutions for reliable dosing control.
FAQs
1. What is the capacity of the Neptune VTF-5HP feeder?
It has a 5-gallon capacity suitable for small to medium closed-loop systems.
2. Is it suitable for high-pressure systems?
Yes, it can handle up to 300 PSI at 200°F, making it ideal for boilers and industrial applications.
3. What is the construction material?
The feeder is made of painted steel with a cast iron cap and a Buna-N O-ring for sealing.
4. Does it include a filter bag?
The 30-micron filter bag kit is available separately as an optional accessory.
5. Where can this feeder be used?
It’s perfect for use in closed-loop systems, HVAC applications, industrial bypass feeders, and cooling towers.
