Pulsafeeder X007-XA-AAAAXXX Metering Pump – 100 Series, 7 GPD, 100 PSI, 115 VAC, Manual Control
Original price was: $707.00.$334.95Current price is: $334.95.
The Pulsafeeder X007-XA-AAAAXXX metering pump from the CHEM-TECH Series 100 is built for reliable and accurate chemical dosing. It delivers up to 7 GPD at 100 PSI, making it ideal for water treatment, chemical feed, and industrial process applications.
This motor-driven diaphragm pump features manual stroke length control, allowing precise flow adjustment from zero to maximum capacity, even while operating. Its sealed gear train and enclosed diaphragm design ensure quiet performance, consistent metering, and long service life with minimal maintenance. Chemical-resistant components provide compatibility with a wide range of water treatment chemicals.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Pulsafeeder X007-XA-AAAAXXX |
| Series | CHEM-TECH 100 Series |
| Type | Motor-driven diaphragm metering pump |
| Flow Capacity | Up to 7 GPD |
| Maximum Pressure | 100 PSI (6.9 bar) |
| Power Supply | 115 VAC, 60 Hz |
| Control Type | Manual stroke adjustment (adjustable during operation) |
| Drive Mechanism | Sealed gear train with eccentric cam |
| Self-Priming | Yes |
| Mounting | Wall or panel mount |
| Pump Head Material | Chemical-resistant thermoplastic |
| Fasteners | Stainless steel |
| Check Valve System | Guided quad check valve |
| Bleed Valve Assembly | Standard on tube connection models |
| Operation | Positive displacement diaphragm |
| Housing | Injection-molded compact housing |
| Applications | Water & wastewater treatment, cooling towers, boiler systems, agricultural dosing, industrial chemical feed |
Dependable Chemical Feed Performance with the Pulsafeeder X007-XA-AAAAXXX
The Pulsafeeder X007-XA-AAAAXXX metering pump delivers consistent and dependable chemical feed for demanding applications. As part of the CHEM-TECH Series 100, it uses a motor-driven diaphragm design to ensure accurate dosing and long-term reliability.
Moreover, the manual control knob allows quick stroke length adjustment from zero to full output. As a result, operators can fine-tune dosing while the pump is running. The sealed gear train and fully enclosed drive also provide quiet operation and added protection from environmental exposure.
In addition, this pump is engineered for low maintenance and high performance. It features renewable valve seats and seals, along with chemical-resistant materials. The self-priming design further simplifies startup and daily operation in Chemical Metering Pumps installations.
Finally, the guided quad check valve system maintains consistent feed rates and helps prevent backflow. This is critical for preserving dosing accuracy in Water Treatment Applications such as cooling towers, boiler systems, and industrial chemical feed. Available from Water Treatment Supply, the Pulsafeeder X007-XA-AAAAXXX is a trusted choice for professionals who value precision, durability, and efficiency.
Specifications and Use Cases of the Pulsafeeder X007-XA-AAAAXXX 7 GPD Metering Pump
The Pulsafeeder X007-XA-AAAAXXX100 combines robust construction with user-friendly control, making it ideal for a range of dosing
applications. Its compact design and reliable drive assembly make it a go-to solution for continuous chemical metering.
Use Cases & Industry Applications:
● Water Treatment Systems: Delivers accurate dosing of chlorine, sodium hypochlorite, or pH adjusters in municipal or industrial systems.
● Cooling Towers & Boilers: Maintains proper biocide or corrosion inhibitor dosing to improve operational efficiency.
● Agricultural Dosing: Enables precise injection of fertilizers, acids, and micronutrients in irrigation systems.
● Industrial Processes: Perfect for dosing chemicals in plating lines, food and beverage plants, and wastewater treatment solutions.
● Pool & Spa Systems: Automates chlorine feed for safe and consistent disinfection.
FAQs
1. What is the flow rate of the Pulsafeeder X007-XA-AAAAXXX?
It delivers up to 7 gallons per day (GPD) at pressures up to 100 PSI, ideal for small to medium chemical feed systems.
2. Can I adjust the dosing output manually?
Yes. The manual stroke length control allows you to adjust output from zero to maximum while the pump is running.
3. Is the pump self-priming?
Yes. It can self-prime up to its maximum rated pressure, making it reliable for off-gassing chemicals.
4. What materials are used in construction?
The pump head and housing are made from chemical-resistant thermoplastics, with stainless steel fasteners for corrosion protection.
5. What’s included with the Pulsafeeder X007-XA-AAAAXXX?
Each unit includes tubing, fittings, a suction strainer, an injection valve, and installation hardware for quick setup.
